Company Profile

    Founded in 1954, Lutz is a family-owned company. Lutz specializes in fluid transportation through barrel pumps and container pumps. In 1954, Karl Lutz founded the Lutz company and began to produce electric barrel pumps and container pumps in Wiltheim. In recent years, the Lutz brand has become synonymous with any liquid filling and delivery system.

     At present, Lutz Group has many very powerful medium-sized enterprises in different industries in Germany and abroad. The addition of these companies has greatly expanded the range of Lutz products. In addition, the internal cooperation between Lutz Pump Co., Ltd., MTE and Lutz-Jesco also enables customers to enjoy more comprehensive services. After Technopool joined the group in 2003, we added swimming pool water treatment equipment to our product line.



technical parameter:



Shell:     PP/316L/aluminum alloy

Gear:     stainless steel

Shaft:       Nickel-based alloy (2.4610)

Seal:     Viton® (optional with FEP)

Measuring range: above 5 centipoise, 3-360 liters/min

Viscosity:     Maximum 500,000 centipoise

Working pressure: up to 16 bar

Accuracy:     +/- 0.5%

Repeatability:   0.03%

Temperature:     Maximum 80 °C

Connection method: G1



advantage:



Touch screen with multi-language operation menu

Simple modular structure. easy to use

Accurate measurement with high repeatability

Basically no need to repeat calibration

Low pressure loss

Comprehensive monitoring and safety functions

External control connection module/data estimation through standard interface

The relay module can be used at any time

Representative application areas are as follows:

Acids and bases, chemical solutions, organic and inorganic compounds, fuels, diesel, motor oil and additives;

Acid-base solution, etching solution, pickling solution, sewage, solvent, thinner, hardener, paint coating, ink;

Cutting oil, refrigerant, hydraulic oil, gear oil, cleaning agent, penetrating fluid;

Flavors and fragrances, vegetable oils, foods, medicines, disinfectants;

Epoxy resin, rubber, adhesive, glue, low viscosity grease, latex, syrup, glucose, cream, mousse;
